| Device Type |
Switch - 16 ports - L3 - managed - stackable |
| Enclosure Type |
Rack-mountable 1U |
| Subtype |
10 Gigabit Ethernet |
| Ports |
16 x 100/1000/2.5G/5G/10GBase-T (PoE+) |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE Budget |
199 W |
| Performance |
Switching fabric bandwidth: 480 Gbps Throughput: 238 Mpps |
| Capacity |
Packet buffer size: 16 MB |
| MAC Address Table Size |
16K entries |
| Jumbo Frame Support |
9KB |
| Routing Protocol |
RIP-2, IGMP, VRRP, OSPFv2, PIM-SM, static IP routing, PIM-DM, OSPFv3, PIM-SSM, ECMP, policy-based routing (PBR), MLD, MSTP, RSTP |
| Remote Management Protocol |
SNMP, RMON, Telnet, SNMP 3, HTTP, HTTPS, SSH-2, CLI, SCP, SFTP, DHCP, IPv4, IPv6, RSTP, TACACS+, RADIUS |
| Encryption Algorithm |
SHA, MD5, SSL 3.0, 2048-bit RSA, 256-bit SHA-2, 512-bit SHA-2, TLS 2.0 |
| Authentication Method |
RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features |
BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), DoS attack prevention, DiffServ support, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, SNTP support, Non-Stop Forwarding (NSF), sFlow, Per-VLAN Spanning Tree Plus (PVST+), Uni-Directional Link Detection (UDLD), LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), Per-VLAN Rapid Spanning Tree (PVRST), Management Information Base (MIB), dual firmware images, Class of Service (CoS), Precision Time Protocol (PTP), Spanning-tree Root Guard (STRG), Authentication, Authorization and Accounting (AAA), User Datagram Protocol (UDP), Protocol Independent Multicast (PIM) |
| Compliant Standards |
IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX |
| Processor |
: 800 MHz |
| RAM |
1 GB |
| Flash Memory |
256 MB |
| Status Indicators |
Status |
