XS724EM-100NAS
48-Port Ethernet L3 Fully Managed Switch, 48 x 100M/1000M/2.5GBASE-T/Multi-Gigabit, with 4 x 25Gb SFP28 and 2 x 40Gb QSFP+ Uplinks
The S5800-48MBQ 48-Port Multi-Gigabit Ethernet layer 3 switch features 48x 100M/1000M/2.5GBASE-T and 4 x 10G/25G SFP28 and 2 x 40G QSFP+ uplinks. This managed enterprise switch delivers 600 Gbps switching capacity and 445.76 Mpps forwarding rate for superior processing performance and network reliability. FS agile S5800-48MBQ managed switch is ideal for next generation enterprise, WIFI6 Access, Metro and HCI (Hyper Converged Infrastructure) networks. Also, this cost-effective campus network switch comes with an industry-leading 5-year limited lifetime warranty and 30-day return policy.
Product Specifications
| Ports |
48x 100M/1000M/2.5GBASE-T, 4x 25Gb SFP28, 2x 40Gb QSFP+ |
Switching Capacity |
600 Gbps |
| Forwarding Rate |
445.76 Mpps |
ARP Table |
12,288 |
| Max./Min. Latency |
Max. 0.96us/Min. 0.66us |
Flash Memory |
8GB EMMC (OS)/4MB SPI Flash (Boot) |
| MAC Address |
98,304 |
Number of VLANs |
4,094 |
| Jumbo Frame |
9,600 |
DRAM |
2GB |
| MLAG |
Support |
BGP |
Support |
| Packet Buffer |
9MB |
MTBF |
99,936.04 |
| Power Device |
1+1 Redundancy Hot-swappable |
Fan Number |
3+1 Redundancy Hot-swappable |
| Airflow |
Front-to-Back |
Warranty |
5 Years
|
