$1,079.99
Product Highlights:
  • Dedicated AV web-based GUI interface for more specific AV installations
  • Color-based AV profiles can be applied to the different ports
  • Dante, Q-SYS, AES67 and AVB audio profiles
  • NVX, SVSI, Q-SYS, NDI and Dante video profiles
  • Audio / video / control mixed profiles
  • Automatic switch interconnect with NETGEAR IGMP Plus
  • Common Layer 2 and Layer 3 switching engine
  • Built-in IT web GUI, console, Telnet and SSH
  • 12-port 100 / 1000 / 2.5GBase-T (RJ-45)
  • 2-port 1000 / 10GBase-X (SFP+)
  • 100 Gbps non-blocking fabric across 14 ports
  • Out-of-band 1G Ethernet management port
  • USB-C and RJ-45 RS232 console ports and USB-A storage port
  • Rack-mounting standard brackets


The NETGEAR M4250 switch series was developed and engineered for audio / video professionals with dedicated service and support. M4250 has been built from the ground up for the growing AV over IP market. AV codecs generally use 1 Gbps or 10 Gbps per stream and the AV Line of M4250 targets the widespread 1 Gbps codecs. M4250 switch comes pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available. For video the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Dante, as well as audio / video / control mixed profiles.

Product Description NETGEAR AV Line M4250-12M2XF - switch - 14 ports - managed - rack-mountable
Device Type Switch - 14 ports - L3 - managed
Enclosure Type Side to side airflow rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 12 x 10/100/1000/2.5G + 2 x 10 Gigabit SFP+
Performance Switching capacity: 100 Gbps
Firewall throughput (64-byte packet size): 74.4 mpps
Latency (2.5 Gbps): 6.013 µs
Latency (10 Gbps): 0.807 µs
Capacity VLANs supported: 4093
ARP entries: 4000
Multicast entries (IPv4): 512
Multicast entries (IPv6): 128
Jumbo frame size: up to 12000
IGMP multicast groups: 2000
MSTP instances: 16
PVST instances: 32
MAC Address Table Size 16K entries
Routing Protocol RIP, IGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, PIM-SSM, static IPv4 routing, static IPv6 routing, MLDv2
Remote Management Protocol RMON 1, RMON 2, SNMP, RMON 9, Telnet, HTTPS, SSH, CLI, TACACS+, RADIUS
Features VLAN support, DoS attack prevention, sFlow, Spanning Tree Protocol (STP) support, DHCP snooping, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), DHCP relay, Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), Dynamic VLAN Support (GVRP), Multiple VLAN Registration Protocol (MVRP), 16MB packet buffer, IP source guard, Bridge protocol data unit (BPDU), GARP Multicast Registration Protocol (GMRP), Spanning-tree Root Guard (STRG), policy based routing, Authentication, Authorization and Accounting (AAA), LLDP-MED, Private VLAN, Protocol Independent Multicast (PIM), Rapid Reconfiguration of Spanning Tree (RSTP), Link Aggregation Group (LAG)
Compliant Standards IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1Qat, IEEE 802.1Qav
Power AC 110 V
Dimensions (WxDxH) 17.3 in x 3.9 in x 1.7 in
Weight 3.85 lbs
Localization Americas
Manufacturer Warranty ProSAFE lifetime warranty
General
Device Type Switch - 14 ports - L3 - managed
Enclosure Type Side to side airflow rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 12 x 10/100/1000/2.5G + 2 x 10 Gigabit SFP+
Performance Switching capacity: 100 Gbps
Firewall throughput (64-byte packet size): 74.4 mpps
Latency (2.5 Gbps): 6.013 µs
Latency (10 Gbps): 0.807 µs
Capacity VLANs supported: 4093
ARP entries: 4000
Multicast entries (IPv4): 512
Multicast entries (IPv6): 128
Jumbo frame size: up to 12000
IGMP multicast groups: 2000
MSTP instances: 16
PVST instances: 32
MAC Address Table Size 16K entries
Routing Protocol RIP, IGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, PIM-SSM, static IPv4 routing, static IPv6 routing, MLDv2
Remote Management Protocol RMON 1, RMON 2, SNMP, RMON 9, Telnet, HTTPS, SSH, CLI, TACACS+, RADIUS
Encryption Algorithm SSL 3.0, TLS 1.2
Features VLAN support, DoS attack prevention, sFlow, Spanning Tree Protocol (STP) support, DHCP snooping, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), DHCP relay, Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), Dynamic VLAN Support (GVRP), Multiple VLAN Registration Protocol (MVRP), 16MB packet buffer, IP source guard, Bridge protocol data unit (BPDU), GARP Multicast Registration Protocol (GMRP), Spanning-tree Root Guard (STRG), policy based routing, Authentication, Authorization and Accounting (AAA), LLDP-MED, Private VLAN, Protocol Independent Multicast (PIM), Rapid Reconfiguration of Spanning Tree (RSTP), Link Aggregation Group (LAG)
Compliant Standards IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1Qat, IEEE 802.1Qav
Processor X ARM A9: 1.25 GHz
RAM 2 GB
Flash Memory 256 MB
Status Indicators Link/speed
Expansion / Connectivity
Interfaces 12 x 10/100/1000/2.5G RJ-45
2 x 10GBase-X SFP+
1 x management (Gigabit LAN) RJ-45
1 x console RJ-45
1 x USB Type A
1 x console (USB) Type C
Power
Power Device Internal power supply
Installed Qty 1
Voltage Required AC 110 V
Power Consumption Operational 37.9 Watt
Power Consumption Stand by 14.1 Watt
Miscellaneous
Included Accessories Mounting brackets
Cables Included Console cable
USB-C to USB-A cable
Rack Mounting Kit Included
Compliant Standards CCC, EN 61000-3-3:2013, EN 55024:2010, YD/T993-1998, IEC60950/EN60950, FCC CFR47 Part 15 B Class A, CNS 13438 Class A, GB 4943.1-2011, EN 55032:2012+AC:2013 Class A, CNS 14336-1, IEEE 1588, ICES-003:2016 issue 6 Class A, CISPR 32:2012, EN 61000-3-2:2014 Class A, VCCI-CISPR 32:2016 Class A, AN/NZS 60950.1:2015, AS/NZS CISPR32:2013 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, EN 60950-1:2006+A1:2010+A11:2009+A2:2013+A12:2011, GB/T9254-2008 Class A, ANSI C63.4:2014
Localization Americas
Dimensions & Weight
Width 17.3 in
Depth 3.9 in
Height 1.7 in
Weight 3.85 lbs
Manufacturer Warranty
Service & Support Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 122 °F
Humidity Range Operating 90% (non-condensing)
Min Storage Temperature -4 °F
Max Storage Temperature 158 °F
Humidity Range Storage 95% (non-condensing)
