Product Overview
CAT6 High Density (HD) CAT6 modular jacks, RJ-45 keystone jacks, is 8-Position 8-Conductor (8P8C) is engineered to provide superior performance and reliability, supporting Gigabit Ethernet applications and beyond. The advanced printed circuit board design is tuned to provide optimum signal quality with maximum headroom, allowing it to exceed TIA CAT6 performance standards. It offers superior signal quality and noise reduction due to its enhanced Near-End and Far-End Crosstalk cancellation and minimum return losses. The CAT6 HD design offers a smaller rear footprint maximizing space in confined work areas.
Main Features
- CAT6 rated connectors provide excellent performance for data networks
- Supports Power over Ethernet (PoE ) Type 4, up to 100W
- PCB technology provides maximum performance and superior signal quality
- Enhanced crosstalk cancellation reduces return loss and improves performance by rejecting noise and unwanted signals
- Exceeds ANSI/TIA-568-C.2 CAT6 connecting hardware requirements
- Designed with rear split back 110 IDC reducing termination time
- Terminate with 110 punch down tool or JackEasy Termination Tool
- Reduced rear footprint allows for greater connectivity density
- Provides for more port configurations in a smaller area
- Includes an integrated TIA-568A/B color wiring diagram
General Information
Name: ICC IC107F6VIV Keystone Jack
Category: ICC, Data Comm & Networking, Cable Connectors, Keystone Jacks
UPC Code: 633758092661
Country of Origin: . Country of origin is subject to change.
