The SP-HD-2B is a compact 2-port HDMI 2.0 splitter that can produce two identical outputs from a single HDMI or DVI source for display on two displays. It supports PC and HD resolutions from 480p up to UHD – 4K @60Hz 4:4:4. It is HDCP 2.2 compliant and supports deep color, 3D, and HDMI audio formats including LPCM 7.1, Dolby TrueHD, and DTS-HD Master Audio. Each HDMI output can be independently downscaled from 4K to 1080p if needed.
The SP-HD-2B also extracts audio from the HDMI source and outputs it as analog (L/R) stereo and digital optical TOSLINK for connection to an audio amplifier or another device. If no display is connected, the SP-HD-2B will emulate a display using an internal EDID, so the source will still output HDMI video, and the splitter will still be able to extract the audio signal.
RS-232 is available for basic configuration and control if needed. For convenience, a pair of mounting brackets and hardware is included for installation either under-desk or surface-mount.
Product Highlights:
- 1×2 HDMI 2.0 Splitter supports PC and HDTV resolutions from VGA to WQXGA and 480p to UHD 4K @60Hz 4:4:4
- 18 Gbps bandwidth for a sharp digital image up to 4Kx2K
- HDCP 2.2 compliant
- Optional Downscaling of 4K to 1080p for each Output
- Extracts HDMI Audio to both L/R analog and TOSLINK (optical)
- Supports LPCM 7.1 CH, Dolby TrueHD, and DTS-HD Master Audio
- Audio extraction does not require connected displays
- Plug and play installation with smart EDID management
- Unplugging one output will not cause interruption of the other
- LED indication for power, source, and output connections
- RS-232 configuration and control
- Mounting brackets included
- Universal power adapter
| Video Standards |
HDMI 2.0 video specifications including 12 bit color depth, 3D video, and 4K/60
DVI (single link)
HDCP 2.2 |
| Connectors |
HDMI (1x INPUT, 2x OUTPUT) |
| Bandwidth |
18 Gbps total |
| Resolutions |
HDTV signal 480i through 4K/60 4:4:4
DVI signal – VGA (640×480) thru WUXGA (1920×1200) |
| Audio |
All HDMI Embedded audio including: LPCM 7.1, Dolby TrueHD, and DTS-HD Master Audio
(32-192 kHz sample rate) |
| Connectors |
3.5mm Stereo Analog
Optical S/PDIF Digital (TOSLINK) |
| Other Signals |
(1) RX, TX and GND on Terminal Strip
RS-232 Baud Rate: 115200, N, 8, 1USB-Mini for FW Update |
| Power |
100 VAC to 240 VAC, 47-63 Hz, External; 5 VDC with universal blades
5VDC, 1.0 A Power Supply 2.2 Watts |
| Temp/Humidity |
Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, non-condensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, non-condensing |
| Cooling |
Convection |
| Enclosure Type |
Metal (Steel) |
| Dimensions |
1.10″ H x 5.35″ W x 2.85″ D (27.9mm H x 135.9mm W x 72.4mm D) |
| Product weight |
Splitter alone: 1.0 lb
Package (shipping): 2.0 lb |
| Vibration |
ISTA 1A in carton (International Safe Transit Association) |
| Safety |
CE |
| EMI/EMC |
CE, FCC Class A |
| MTBF |
90,000 hours (Calculated Estimate) |
| Warranty |
3 years parts and labor |
