| Supported Resolutions |
4K DCI (4096 x 2160 at 24 Hz)
4K Ultra HD (3860 x 2160 at 60 Hz, 4:2:0 color space)
1080p Full HD
1920x1200 WUXGA |
| HDCP |
v1.4 Compliant |
| Deep Color |
Supports 12-bit Deep Color (up to 1080p) |
| EDID |
Advanced EDID management |
| Audio Support |
LPCM 7.1, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio |
| Maximum Pixel Clock |
300 MHz |
| Ports and Connectors |
8 x Locking HDMI Type A female inputs
8 x Locking HDMI Type A female outputs
1 x USB mini-B
1 x RS-232
1 x RJ-45 Ethernet
1 x 4-pin DC power connector |
| LED Indicator: |
1 x Red/Green power indicator
1 x Orange lock indicator |
| Display Type |
2 x 16-Character rows |
| Control Buttons |
7 x tact type |
| IR Sensor |
1 x front panel sensor 1 x 3.5mm mini stereo extender port |
| Power Supply |
24 VDC |
| Power Consumption |
27 W Maximum |
| Operating Temperature |
32 to 122°F / 0 to 50°C |
| Storage Temperature |
-4 to 140°F / -20 to 60°C |
| Operating Humidity |
5 to 90% RH (non-condensing) |
| Storage Humidity |
5 to 95% RH (non-condensing) |
| Dimensions |
9.3 x 17.9 x 1.75" / 236 x 454 x 44 mm |
| Weight |
3.9 lb / 1.8 kg |
